Selecting a M edia
Size
QMS 3825/3225/2025 Userîš’s Guide2-10
Media Sizes
The printer supports the following media sizes:
Selecting a Media Size
Input bins for letter and ledger or A3 and A4 sizes are standard. Each
standard input bin has a special metal tab that the printer uses to
sense the media size loaded in the bin. If you modify one of the stan-
dard input bins, you must also replace this tab. The optional large-
large capacity input bin can also be modified to accept different paper
sizes. See the instructions for changing an input bin’s media size later
in this chapter.
When you use a media size selection command, the printer searches
the input bins for the matching media size. When it finds a match, it
uses media from that bin to print your file. If you know the printer has
been loaded with a certain media, you can use the media size selec-
tion commands to select the input bin containing that media even if
you do not know the input bin number. (See the
QMS Crown Docu-
ment Option Commands
manual for complete information about
using DOC in your files.)
Media Media Size Imageable Area Feed
Edge
Inches Millimeters Inches Millimeters
A3
11.75 x 16.50 297 x 420 11.38 x 16.22 289 x 412 Short
A4
8.27 x 11.75 210 x 297 7.93 x 11.38 202 x 289 Long
A5R
5.83 x 8.27 148 x 210 5.51 x 7.96 140 x 202 Short
B4
9.85 x 12.88 250 x 327 9.53 x 12.57 242 x 319 Short
B5
7.17 x 10.12 182 x 257 6.86 x 9.81 174 x 249 Long
Executive
10.50 x 7.50 267 x 190 10.33 x 7.33 262 x 186 Long
Ledger
11.00 x 17.00 279 x 432 10.67 x 16.67 271 x 424 Short
Legal
8.50 x 14.00 216 x 356 8.17 x 13.67 208 x 348 Short
Letter
8.50 x 11.00 216 x 279 8.17 x 10.67 208 x 271 Long
