Xerox 7800 User Manual

Maintenance
Xerox
®
WorkCentre
®
7800/7800i Series Color Multifunction Printer 205
User Guide
4. Each of the four printheads has its own cleaning tool. Slowly pull the LED printhead cleaner out until
the three dots are visible.
Note: The LED printhead cleaner does not detach from the printer.
5. Slowly push the LED printhead cleaner back into the printhead until it stops.
6. Repeat Steps 4 and 5 for each printhead.
7. Close the drum cartridge cover.
8. Turn the belt tension lever to the right to return it to the locked position.
9. Close the printer front cover.

Xerox 7800 Specifications

General

Maximum Print Resolution	1200 x 2400 dpi
Duplex Printing	Yes
Fax Speed	33.6 Kbps
Functions	Print, Copy, Scan, Fax
Connectivity	Ethernet, USB
Display	Color touch screen
