Maintenance
216 Xerox
®
WorkCentre
®
7800/7800i Series Color Multifunction Printer
User Guide
Replacing the Second Bias Transfer Roller
1. A message appears on the control panel when the second bias transfer roller must be replaced.
Remove paper from the left tray, then fold up the tray.
2. Open tray 5 (bypass) as shown (1).
3. While lifting up the release lever (2), open the top left cover A as shown (3).
WARNING: The area around the fuser can be hot. Use caution to avoid injury.
CAUTION: Do not touch the transfer belt. Touching the belt can reduce image quality or damage the
transfer belt. Do not touch the transfer roller. Touching the roller can reduce image quality.
