Troubleshooting
280 Xerox
®
WorkCentre
®
7800/7800i Series Color Multifunction Printer
User Guide
Clearing Main Staple Jams in the Professional Finisher
WARNING: Do not perform this procedure while the printer is copying or printing.
1. Open the front door of the finisher.
2. Hold the staple cartridge unit by orange lever R1 and push it to the right.
3. Grip the staple cartridge by the orange tabs and pull it firmly toward you to remove it. Check inside
the finisher for any loose staples and remove them.
4. Pull the staple cartridge clamp firmly in the direction shown to open it.

Xerox 7800 Specifications

General

Maximum Print Resolution	1200 x 2400 dpi
Duplex Printing	Yes
Fax Speed	33.6 Kbps
Functions	Print, Copy, Scan, Fax
Connectivity	Ethernet, USB
Display	Color touch screen
