Xerox 7800

Maintenance
Xerox
®
WorkCentre
®
7800/7800i Series Color Multifunction Printer 215
User Guide
7. Remove the protective cover from the new transfer belt cleaner.
CAUTION: Do not touch the surface of the transfer belt cleaner. Doing so could deteriorate image
quality.
8. Support the new transfer belt cleaner with your left hand and slide it straight into the opening until
it stops.
9. Push the orange knob in, then turn it clockwise until snug.
10. Turn the orange lever to the left to lock the belt cleaner.
11. Close the printer front cover.
