Troubleshooting
278 Xerox
®
WorkCentre
®
7800/7800i Series Color Multifunction Printer
User Guide
8. Grip the staple cartridge by the orange handle and insert it into the stapler until it clicks to lock in
place.
9. Close the finisher front door.
Clearing Booklet Staple Jams in the Office Finisher LX
The stapler in the booklet maker uses two staple cartridges labeled R2 and R3. Booklet stapling requires
that both staple cartridges be free of jammed staples.
WARNING: Do not perform this procedure while the printer is copying or printing.
1. Open the finisher side cover.
2. If the staple cartridges are not visible, grip the vertical panels at the left and right of the opening
and slide them to the center.
