Menu item
Description
• This menu item activates vertical escapement
that causesthe selected number of requested lines
to print between the default margins of the page.
• 60 is the U.S. factory default setting. 64 is the
international factory default setting.
PCL5 Minimum Line Width
1–30 (2*)
Set the initial minimum stroke width.
Jobs printed in 1200 dpi use the value directly.
PCLXL Minimum Line Width
1–30 (2*)
A4 Width
198mm*
203mm
Set the width of the logical page on A4-size paper.
Logical page is the space on the physical page where
data is printed.
Auto CR after LF
Off*
On
Set the printer to perform a carriage return after a
line feed control command.
Carriage return is a mechanism that commands the
printer to move the position of the cursor to the first
position on the same line.
Auto LF after CR
Off*
On
Set the printer to perform a line feed after a carriage
return control command.
Tray Renumber
Assign MP Feeder
Assign Tray [x]
Assign Manual Paper
Assign Manual Envelope
Configure the printer to work with a different print
driver or custom application that uses a different set
of source assignments to request a given paper
source.
Choose from the following options:
Off*—The printer uses the factory default paper
source assignments.
None—The paper source ignores the Select Paper
Feed command.
0–199—Select a numeric value to assign a custom
value to a paper source.
Tray Renumber
View Factory Defaults
Show the factory default value assigned for each
paper source.
Tray Renumber
Restore Defaults
Restore the tray renumber values to their factory
defaults.
Xerox
®
B310 Printer
User Guide
73
Use Printer Menus
