2. Locate and hold the stapler assembly by the orange lever R1, then push it to the right.
3. To remove the staple cartridge, grasp the orange handle, then pull it firmly toward you.
4. Pull the staple cartridge clamp firmly in the direction shown to open it.
5. Remove the jammed staples.
WWaarrnniinngg:: The points of the jammed staples are sharp. Remove the jammed staples carefully.
Xerox
®
EC8036/EC8056 Color Multifunction Printer User Guide 297
Troubleshooting
