General Procedures / Information
6-36 12/04 FaxCentre F110
Fan (Test-Code 120)
Checks the function of the fan
Flow:
Pass:
All Tests ok, no anomaly occurred
Resultbytes:
00 Test ok
FF Test not done
80 … Operator pressed <STOP>
Table 1:
Step Status Operator UUT Display Remarks
1 Is in Testmode and wait
for command
YYY TESTMODE
XX
YYY…last Testcode
XX…Errorcode or 00
2 Enter Command Keypad: 120
4 Open and close printer
cover
Switch fan on and wait
for input
FAN TST
5 Check function of fan
by hand
.
7 OK Press <START> Set Resultbyte to 00 120 TESTMODE 00 XX = 00 and no anomaly
occurred
8 NOK Press <STOP> Set Resultbyte to XX 120 TESTMODE XX XX <> 00 or anomaly
occurred
