General Procedures / Information
FaxCentre F110 12/04 6-35
Sensors (Test-Code 112)
Checks the Cover Sensor and the Paper-Cassette sensor.
Flow:
Pass:
Resultbytes:
00 ... Test ok
FF ... Test not done
All other bit combinations means error (anomaly occurred).
Table 1:
Step Status Operator UUT Display Remarks
1 Is in Testmode and wait for
command
YYY TESTMOD XX YYY…last Testcode
XX…Errorcode or 00
2 Enter Command Keypad: 112
3SEN TST
4 Checks Paper Cassette
sensor
REMOVE PAP
CASS
Remove Paper Cassette INSERT PAP CASS
5 Insert Paper Cassette Checks Paper Cassette
sensor
OPEN PRT COVER
6 Open Printer Cover Checks Cover sensor CLOSE PRT
COVER
7 Close Printer Cover Checks Cover sensor WAIT PRT READY
9 OK Set Resultbyte to 00 112 TESTMODE
XX
XX = 00 and no
anomaly occurred
10 NOK Set Resultbyte to XX 112 TESTMODE
XX
XX <> 00 or anomaly
occurred
