Xerox FaxCentre F110 Service Manual

Repairs/Adjustments
FaxCentre F110 12/04 4-9
Remove Top Cover Main Housing
CAUTION
Do not remove the LSU. The LSU is factory set and can only be installed as part of the Main
Cover.
1. Remove the 4 screws (see Figure 4), and 2 screws inside the machine (under the print car-
tridge).
Figure 4
LSU. See Caution.
