3-3
Phaser 3635MFP
IQ1
Image Quality
Draft 4
IQ1 Image Quality Entry RAP
Use this RAP to determine the source of an image quality problem.
Initial Actions
• Check the condition of the paper. Do not use incorrectly cut paper, damp paper, paper
with rough edges, badly drilled paper, paper with wrapper wax or glue. Paper and media
should be stored flat, enclosed in wrappers, in a cool dry environment.
• Check that the paper is within specifications. Refer to GP 9 Paper and Media Specifica-
tions.
• Check that paper tray guides are set to the correct paper size.
• Check the document guides on the DADF.
• Check the original documents for defects.
• Ensure that the image adjustment mode selections are those used by the customer.
• Check that the machine fans are working, go to the OF3 Air Systems RAP.
Procedure
If necessary, refer to IQ1 Internal Test Patterns for:
• A description of image quality defects.
• The optimum test pattern to be used to diagnose the defect.
• An example of all internal test patterns.
If possible, use the customer job to recreate the image quality problem.
Enter dC606. Select a suitable test pattern. Select the Features, 1 or 2 sided and paper size.
Press Start Test. Go to the relevant RAP:
• IQ2 Blank Copies RAP
• IQ3 Black Copies or Prints RAP.
• IQ4 Blurred Image From the Scanner RAP
• IQ5 Vertical Black Lines or Bands RAP
• IQ6 Vertical White Lines RAP
• IQ7 Light Image RAP
• IQ8 Dark Image RAP
• IQ9 Background RAP
• IQ10 Ghost Images RAP
• IQ11 Stains on Back of Paper RAP
• IQ12 Poor Fusing RAP
• IQ13 Partial Blank Image (Not Periodic) RAP
• IQ14 Partial Blank Image (Periodic) RAP
• IQ15 Different Image Density (Left and Right) RAP
• IQ16 Horizontal Bands RAP
• IQ17 Periodic Printing Defects Check RAP
• IQ18 DADF Lead Edge Offset RAP
• IQ19 Poor Registration RAP.
IQ1 Internal Test Patterns
Table 1 defines the image defect, gives a description of the defect and identifies the optimum
test pattern to be used.
NOTE: There are 19 internal test patterns, but only 7 are unique. Each test pattern is available
more than one time. Only the first occurrence of a test pattern is shown in Table 1.
Table 2 describes the test patterns and the purpose for which they should be used to identify
image quality defects.
Table 1 Image quality defects
Image quality
defect Description of defect
Optimum
internal test
pattern
Background Uniform darkening across all the non print areas 1
Bands Grey to dark in the light or non-image areas of the print in the
process direction or across the process direction. See also
narrow bands.
1
Beads on print Developer beads in the light or non-image areas of the print. 1, 7, 8
Black image A print that is black or grey all over, but has no visible image
of the original document.
1, 7, 8
Blank image No visible image. 1, 7, 8
Blurred image Part or whole of the image has the appearance of being out
of focus.
1, 7, 8
Dark prints Very dark background with a visible image. 1, 7, 8
Deletions Areas of the image missing from the print. Deletions may be
in the form of white spots, marks, lines, or whole areas of
toner missing from the print.
1, 6
Displaced and
fragmented
Distorted images, part images and missing images (scram-
bled images). Displaced images.
1
Light image The image is visible on the print, but with insufficient solid
area density.
1
Lines Black or white lines across the process direction or in the pro-
cess direction. See also the description, displaced and frag-
mented image.
1, 7
Magnification At 100% magnification the printed image differs from the size
of the image on the original document.
7
Marks Dark marks in the non-image areas of the print. 1, 7
Misregistration The image on the paper is misregistered. 7
Narrow Bands Bands across the process direction visible in halftone areas. 1, 4, 5
Non uniformity Variation in image quality and density across the print. See
also uneven density.
4, 5
Offsetting A previous image that was not removed from the fuser roll
during the cleaning cycle. The image is repeated at regular
intervals.
1, 5

Xerox Phaser 3635MFP Specifications

General

Network ready	Yes
Dimensions (WxDxH)	472 x 478 x 54 mm
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Digital sender	No
Maximum duty cycle	75000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, Fax, FTP, USB
Maximum scan area	220 x 300 mm
Image formats supported	JPG, TIF
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	199
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	250 sheets
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	60 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Security algorithms	802.1x RADIUS, HTTPS
Supported network protocols (IPv4)	FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP, UDP
Internal memory	512 MB
Card reader integrated	-
Internal storage capacity	80 GB
Sound pressure level (printing)	59 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	15 W
Power consumption (PowerSave)	55 W
Power consumption (average operating)	600 W
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	10 - 32 °C
Operating temperature (T-T)	16 - 30 °C
Storage relative humidity (H-H)	20 - 80 %
Operating relative humidity (H-H)	30 - 70 %
Sustainability certificates	ENERGY STAR
Certification	CE, FCC, RoHS
