Xerox Phaser 3635MFP User Manual

6-6
Phaser 3635MFP
GP 2
Draft 4
General Procedures and Information
GP 2 Fault Codes and History Files
Purpose
To explain the chain code structure and describe fault history contents.
Description
• To access some history files from the UI, refer to GP 3 machine Status.
• To view all the machine fault history, clear the last 40 faults, or reset each of the fault
counters, refer to Diagnostics Fault History.
• For information on fault codes, refer to Function and Fault Codes.
Procedure
1. Enter diagnostics, GP 1.
2. Select the Fault History tab.
3. Select Fault Log or Fault Counters button as appropriate and follow the on screen
instructions.
Function and Fault Codes
Refer to Table 1 Function and fault code prefixes. Also known as the chain code.
NOTE: Where possible, the component related fault codes are the same as the component
control codes.
Machine Status Button Fault History
The most recent fault and status codes can be displayed on the UI. Press the Machine Status
key, refer to GP 3. Touch the ‘Error Messages’ tab on the UI, then select, as appropriate:
•All Faults.
• Active Messages - status codes and a status message.
• Event Log.
Diagnostics Fault History
Description
The diagnostics Fault History window contains two options:
1. Fault Log - Displays the faults in time or code order. Displays a selected fault in detail.
Permits deletion of the entire history file.
2. Fault Counters - Displays the title buttons for the faults separated into chains. Selection of
a chain will display the fault detail.
NOTE: Categories that do not exist on the machine will not be displayed.
Table 1 Function and fault code prefixes
Chain Code Function
01 Electrical
02 USB
03 Run control
04 Drives and fans
05 DADF
06 LSU (ROS)
07 Paper tray
08 Paper feed
09 Xerography
10 Fusing
14 Scanner
15 Scan to Email
17 Network
20 Fax

Xerox Phaser 3635MFP Specifications

General

Network ready	Yes
Dimensions (WxDxH)	472 x 478 x 54 mm
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Digital sender	No
Maximum duty cycle	75000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, Fax, FTP, USB
Maximum scan area	220 x 300 mm
Image formats supported	JPG, TIF
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	199
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	250 sheets
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	60 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Security algorithms	802.1x RADIUS, HTTPS
Supported network protocols (IPv4)	FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP, UDP
Internal memory	512 MB
Card reader integrated	-
Internal storage capacity	80 GB
Sound pressure level (printing)	59 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	15 W
Power consumption (PowerSave)	55 W
Power consumption (average operating)	600 W
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	10 - 32 °C
Operating temperature (T-T)	16 - 30 °C
Storage relative humidity (H-H)	20 - 80 %
Operating relative humidity (H-H)	30 - 70 %
Sustainability certificates	ENERGY STAR
Certification	CE, FCC, RoHS
