Disassembly and Reassembly
6. If necessary, apply light pressure to the both side of
the Jam Cover and pull it in the direction of arrow, as
shown below.
7. Pull the DC Fan from the Middle Cover Ass'y, as
shown below.
Jam Cover
DC Fan
