Xerox Phaser 6120 - Understanding the Media Path

Understanding the Media Path104
Understanding the Media Path
Understanding the printer’s media path will help you locate media misfeeds.
1 Output tray
2 Transfer belt
3 Toner cartridge carousel
4 Imaging unit
5 Tray 1
6 Tray 2 (optional)
7 Duplex unit (optional)
8 Fuser
1
2
4
5
6
7
8
3
