Xerox Phaser 6120 User Manual

About the Control Panel42
SERVICE MENU
With this menu, the service representative can adjust the printer and perform
maintenance operations. This menu cannot be used by the user.
FORMAT FORMAT
FLASH
Settings
NO/YES
Select whether or not to initialize the flash RAM.
If YES is selected, the flash RAM is initialized.
FORMAT
DISK
Settings
NO/YES
Select whether or not to initialize the hard disk.
If YES is selected, the hard disk is initialized.
RESTORE /
SAVE
RESTORE
FACTORY
Settings
NO/YES
Select whether or not all menu items are reset to their
initial settings.
If YES is selected, all menu items are reset to their
initial settings.
SAVE
CUSTOM
Settings
NO/YES
Select whether or not all changed menu settings are
saved.
If YES is selected, all changes are saved.
RESTORE
CUSTOM
Settings
NO/YES
Select whether or not menu items are reverted to the
previously saved settings.
If YES is selected, the menu items revert to the
previously saved settings.

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
