Xerox PrimeLink B9100 User Manual

Clearing Paper Jams from Trimmer Area E1
1. Open the trimmer upper cover.
2. To remove the jammed paper, perform the following steps:
Note: Check behind the upper cover for any hidden jammed paper.
a. Push down lever 11aa.
b. Push down lever 11bb.
c. Lift lever 11dd.
d. Remove the jammed paper.
3. If you have difficulty removing any paper jams, perform the following steps:
a. Rotate knob 11cc clockwise.
b. Remove the jammed paper.
386
Xerox
®
PrimeLink
®
B9100/B9110/B9125/B9136 Copier/Printer User Guide
Crease and Two-Sided Trimmer

Xerox PrimeLink B9100 Specifications

General

Recommended Monthly Print Volume	70, 000 - 700, 000 pages
Duplex Printing	Standard
Type	Multifunction Printer
Print Technology	Laser
Supported Operating Systems	Windows, Mac OS, Linux
Print Resolution	2400 x 2400 dpi
First-page-out time, printing	4.1 seconds
Network Connectivity	Ethernet
Supported Media Sizes	A3, A4, A5, B4, B5
Weight	210 kg
Print Speed (Black)	100 ppm
