Paper Tray Information
Print Engine Trays 1, 2 and 3
When the press is first installed, the tray size setting for Trays 1 and 3 are set at 8.5 x
11 inches or A4 (LEF). The tray size setting for Tray 2 is set at 11 x 17 inches or A3 (SEF).
The specifications for each tray are:
• Maximum of 550 sheets of 24 lb.(90 gsm) uncoated paper; 28 lb. to 80 lb. cover
(105-120 gsm) coated stock
• Paper weight range of 18 lb. Bond to 95 lb. Cover (64 gsm to 256 gsm)
• Paper sizes starting at 7.2 x 7.2 in. (182 x 182 mm) to a maximum of 13 x 19.2 in.
(330 x 488 mm)
• If using the optional Postcard bracket, minimum size is 101.6 x 152.4 mm (4 x 6
inches)
Note
For more information on the optional Postcard bracket, refer to the Paper and Media
section of this guide.
• Stock types include transparencies, heavyweight, coated and uncoated, predrilled,
and tabs
• Loading paper Long Edge Feed (LEF)/portrait or Short Edge Feed (SEF)/landscape
(dependent on the actual paper size)
• Auto size detection capability
• Automatically adjusts the tray position in the front and back based on the paper size;
this is done once the tray is closed
Bypass Tray 5
• Maximum of 250 sheets of 24 lb. (90 gsm) uncoated paper; 28 lb. to 110 lb. cover
(106-300 gsm) coated stock
• Paper weight range of 52 gsm (uncoated) to 300 gsm (coated)
• Stock types include transparencies, heavyweight, coated and uncoated, predrilled,
and tabs
Throughput / Productivity Information
Process and print speed is based on simplex/duplex mode, paper type, paper weight,
paper size and feeding tray.
Table 1: Trays 1, 2 and 3 in LEF Feed Direction
Prints Per MinuteSimplex/DuplexPaper WeightPaper Type
100 ppm / 50 ppmSimplex / Duplex64 to 256 gsm8.5 x 11 / A4 uncoated
and coated
40 ppmSimplex106 to 256 gsm8.5 x 11 / A4 Labels
and Transparencies
