3. Current sampling zero calibration (F1-02)

After the servo drive updated to latest software version, or the motor does not revolve

smoothly for long time, the current offset auto-adjustment is recommended.

Press STATUS/ESC to exit, need to power on again.

4. Panel enable

Parameter

Signal

name

Setting

Meaning

Modify

Effective

P0-03

Enable

mode

Not enable

Servo

OFF

At once

1 (default)

I/O enable /S-ON

Software enable (F1-05 or

communication)

Fieldbus enable (support motion

fieldbus model)

F1-02

F1-01

Press ENTER

INC

Keep Press ENTER

DEC

Motor reverse run

Motor forward run

STA/ESC

F1-01

Keep press ENTER

Press ENTER

rEF

donE
