Page 24
n
Quick Break Down Guide, Continued....
mAINTENANCE AND qUICK bREAK DOWN GUIDE
Remove the two 3 x 8mm machine screws from the
bottom of the chassis that hold the receiver mounting
box in place.
Pull the receiver mounting box up and out of the chassis.
Remove the receiver box lid, then unplug the steering
servo and throttle channel leads from the receiver.
B
Continued On Next Page
A
C
To Next Page
