Page 38
STEP 21: SERVO SAVER AND STEERING LINKAGES
ExPLODED vIEW ASSEmbLY DRAWINGS
(148558) Lock Nut 3mm -- 4
(148625) Shim 8 x 12 x 0.8mm -- 2
(148509) Cap Screw 3 x 20mm -- 2
(149567) Bushing 6 x 10 x 3mm -- 4
(149559) Flanged Ball Bearing 5 x 8 x 2.5mm -- 2
(149457) Servo Saver Screw 3 x 19.7mm -- 2
Continued On Next Page
