Page 37
STEP 19: CHASSIS
(148558) Lock Nut 3mm -- 8
(148539) Flat Head Screw 3 x 10mm -- 8
(148548) Flat Head Screw w/Threadlock 4 x 10mm -- 2
ExPLODED vIEW ASSEmbLY DRAWINGS
STEP 20: STEERING TIE-RODS
(149331) Turnbuckle 4 x 48mm -- 2
Continued On Next Page
