Page 32
STEP 9: FRONT SUSPENSION
(148558) Lock Nut 3mm -- 2
(148615) Button Head Tapping Screw 4 x 8mm -- 2
(149901) Hinge Pin 4 x 67.5mm -- 2
(148648) Cap Screw 3 x 45mm -- 2
STEP 10: REAR GEARBOX
(148615) Button Head Tapping Screw 4 x 8mm -- 2
(148583) Button Head Tapping Screw 3 x 38mm -- 2
ExPLODED vIEW ASSEmbLY DRAWINGS
(148584) Button Head Tapping Screw 4 x 12mm -- 2
(148559) Lock Nut 4mm -- 1
(148507) Cap Screw 4 x 50mm -- 1
Continued On Next Page
To Next Page
