XTM Racing RAIL - Steering Linkage Mounting

Page 45
ExPLODED vIEW ASSEmbLY DRAWINGS
STEP 30: STEERING LINKAGE MOUNTING
(148558) Lock Nut 3mm -- 2
(148627) Button Head Screw 3 x 20mm -- 2
(148659) Button Head Screw 3 x 22mm -- 2
(148554) Washer Head Screw w/Threadlock 4 x 10mm -- 2
(148579) Button Head Tapping Screw 3 x 15mm -- 1
(148621 ) Shim 6 x 9.8 x 0.2mm -- 2











Continued On Next Page
