Page 35
STEP 15: REAR SUSPENSION
(148560) Flanged Lock Nut 3mm -- 2
STEP 16: REAR SWAY BAR
(149293) Threaded Stud 3 x 12mm -- 2
(148509) Cap Screw 3 x 20mm -- 2
(149901) Hinge Pin 4 x 67.2mm -- 2
(148584) Button Head Tapping Screw 4 x 12mm -- 2
ExPLODED vIEW ASSEmbLY DRAWINGS
(148566) Grub Screw w/Threadlock 3 x 3mm -- 2
(148570) Grub Screw w/Threadlock 4 x 4mm -- 2
(148601) Flat Head Tapping Screw 3 x 12mm -- 4
(148542) Flat Head Screw 3 x 20mm -- 2
Continued On Next Page
