Page 42
ExPLODED vIEW ASSEmbLY DRAWINGS
STEP 26: FRONT SHOCK MOUNTING
(148560) Flanged Lock Nut 3mm -- 2 (148542) Flat Head Screw 3 x 20mm -- 2


STEP 27: REAR SHOCK MOUNTING
(148560) Flanged Lock Nut 3mm -- 2 (148542) Flat Head Screw 3 x 20mm -- 2












Continued On Next Page
