Page 39
STEP 22: MOTOR MOUNTING AND CENTRE DIFFERENTIAL
(148570) Grub Screw w/Threadlock 4 x 4mm -- 1
ExPLODED vIEW ASSEmbLY DRAWINGS
(150040) Post 6 x 6mm -- 8
(148509) Cap Screw 3 x 20mm -- 8
(148576) Button Head Tapping Screw 3 x 10mm -- 2
(148525) Button Head Screw w/Threadlock 3 x 8mm -- 2
(148527) Button Head Screw w/Threadlock 3 x 12mm -- 4
Continued On Next Page
