Quick Break Down Guide, Continued....
mAINTENANCE AND qUICK bREAK DOWN GUIDE
Remove the four 4 x 16mm self-tapping screws from
the bottom of the chassis that hold the rear suspension
assembly in place.
Remove the 3 x 20mm machine screw and the lock nut
that hold the front of the rear suspension mounting brace
in place.
Pull the rear suspension assembly,
along with the rear centre dog bone,
up and off the chassis.
A
C
B
A
