THREE PHASE, 4" MOTOR DATA
Electrical Data, 60 Hz, 3450 RPM
Full Load Service Factor
Locked
Line - Line
Model # HP kW Volts SF Amps Watts Amps Watts
Rotor Amps
Resistance
M05430 0.5 0.37 1.6 2.9 600 3.4 870 22 4.1-5.2
M07430 0.75 0.55 1.5 3.8 812 4.5 1140 32 2.6-3.0
M10430 1 0.75 1.4 4.6 1150 5.5 1500 29 3.4-3.9
M15430 1.5 1.1
200
1.3 6.3 1560 7.2 1950 40 1.9-2.5
M20430 2 1.5 1.25 7.5 2015 8.8 2490 51 1.4-2.0
M30430 3 2.2 1.15 10.9 2890 12.0 3290 71 0.9-1.3
M50430 5 3.7 1.15 18.3 4850 20.2 5515 113 0.4-0.8
M75430 7.5 5.5 1.15 27.0 7600 30.0 8800 165 0.5-0.6
M05432 0.5 0.37 1.6 2.4 610 2.9 880 17.3 5.7-7.2
M07432 0.75 0.55 1.5 3.3 850 3.9 1185 27 3.3-4.3
M10432 1 0.75 1.4 4.0 1090 4.7 1450 26.1 4.1-5.1
M15432 1.5 1.1
230
1.3 5.2 1490 6.1 1930 32.4 2.8-3.4
M20432 2 1.5 1.25 6.5 1990 7.6 2450 44 1.8-2.4
M30432 3 2.2 1.15 9.2 2880 10.1 3280 58.9 1.3-1.7
M50432 5 3.7 1.15 15.7 4925 17.5 5650 93 .85-1.25
M75432 7.5 5.5 1.15 24 7480 26.4 8570 140 .55-.85
M05434 0.5 0.37 1.6 1.3 610 1.5 875 9 23.6-26.1
M07434 0.75 0.55 1.5 1.7 820 2.0 1140 14 14.4-16.2
M10434 1 0.75 1.4 2.2 1145 2.5 1505 13 17.8-18.8
M15434 1.5 1.1 1.3 2.8 1560 3.2 1980 16.3 12.3-13.1
M20434 2 1.5 460 1.25 3.3 2018 3.8 2470 23 8.0-8.67
M30434 3 2.2 1.15 4.8 2920 5.3 3320 30 5.9-6.5
M50434 5 3.7 1.15 7.6 4810 8.5 5530 48 3.58-4.00
M75434 7.5 5.5 1.15 12.2 7400 13.5 8560 87 1.9-2.3
M100434 10 7.5 1.15 15.6 9600 17.2 11000 110 1.8-2.2
M15437 1.5 1.1 1.3 2.0 1520 2.4 1950 11.5 19.8-20.6
M20437 2 1.5 1.25 2.7 1610 3.3 2400 21 9.4-9.7
M30437 3 2.2 575 1.15 3.7 2850 4.1 3240 21.1 9.4-9.7
M50437 5 3.7 1.15 7.0 5080 7.6 5750 55 3.6-4.2
M75437 7.5 5.5 1.15 9.1 7260 10.0 8310 55 3.6-4.2
