WARNING
Hazardous voltage
can shock, burn or
cause death.
Troubleshooting
DISCONNECT AND LOCKOUT ELECTRICAL POWER BEFORE
ATTEMPTING ANY SERVICE. FAILURE TO DO SO CAN CAUSE
SHOCK, BURNS OR DEATH.
Symptom Probable Cause Recommended Action
PUMP MOTOR
NOT RUNNING
LITTLE OR
NO LIQUID
DELIVERED
BY PUMP
1. Motor thermal protector tripped
a. Incorrect control box
b. Incorrect or faulty electrical
connections
c. Faulty thermal protector
d. Low voltage
e. Ambient temperature of control
box/starter too high
f. Pump bound by foreign matter
g. Inadequate submergence
2. Open circuit breaker or blown fuse
3. Power source inadequate for load
4. Power cable insulation damage
5. Faulty power cable splice
1. Allow motor to cool, thermal
protector will automatically reset
a – e. Have a qualied electrician
inspect and repair, as required
f. Pull pump, clean, adjust set
depth as required
g. Conrm adequate unit
submergence in pumpage
2. Have a qualied electrician inspect
and repair, as required
3. Check supply or generator capacity
4 – 5. Have a qualied electrician
inspect and repair, as required
1. Faulty or incorrectly installed
check valve
2. Pump air bound
3. Lift too high for pump
4. Pump bound by foreign matter
5. Pump not fully submerged
6. Well contains excessive amounts
of air or gases
7. Excessive pump wear
8. Incorrect motor rotation
– three phase only.
1. Inspect check valve, repair as
required
2. Successively start and stop pump
until ow is delivered
3. Review unit performance, check
with dealer
4. Pull pump, clean, adjust set depth
as required
5. Check well recovery, lower pump
if possible
6. If successive starts and stops does
not remedy, well contains exces-
sive air or gases
7. Pull pump and repair as required
8. Reverse any two motor electrical
leads
