DEFINITE PURPOSE THREE PHASE STARTERS WITH
ADJUSTABLE OVERLOADS
CentriPro
Order No.
Eaton Reference
Number
Maximum
Amps
Supply
Voltage
O.L.
Relay
Overload
Range
Maximum
LRA
Typical HP
Range
DP25D2 A27CGC25BA2P4
25 208-230
D 1.6-2.4
150 .5 - 5
DP25E2 A27CGC25BA004 E 2.4-4
DP25F2 A27CGC25BA006 F 4-6
DP25G2 A27CGC25BA010 G 6-10
DP25H2 A27CGC25BA016 H 10-16
DP25J2 A27CGC25BA024 J 16-24
DP25C4 A27CGC25CA1P6
25 460
C 1-1.6
125 .5 - 10
DP25D4 A27CGC25CA2P4 D 1.6-2.4
DP25E4 A27CGC25CA004 E 2.4-4
DP25F4 A27CGC25CA006 F 4-6
DP25G4 A27CGC25CA010 G 6-10
DP25H4 A27CGC25CA016 H 10-16
DP25J4 A27CGC25CA024 J 16-24
DP25E5 A27CGC25DA004
25 575
E 2.4-4
100 1.5 - 10
DP25F5 A27CGC25DA006 F 4-6
DP25G5 A27CGC25DA010 G 6-10
DP25H5 A27CGC25DA016 H 10-16
DP30L2 A27CGE30BA010
30 208-230
L 6-10
180 1.5 - 7.5
DP30M2 A27CGE30BA016 M 10-16
DP30N2 A27CGE30BA024 N 16-24
DP30P2 A27CGE30BA040 P 24-40
DP30L4 A27CGE30CA010
30 460
L 6-10
150 5 - 20
DP30M4 A27CGE30CA016 M 10-16
DP30N4 A27CGE30CA024 N 16-24
DP30P4 A27CGE30CA040 P 24-40
DP30L5 A27CGE30DA010
30 575
L 6-10
120 5 - 15
DP30M5 A27CGE30DA016 M 10-16
DP30N5 A27CGE30DA024 N 16-24
DP30P5 A27CGE30DA040 P 24-40
DP30R5 A27CGE30DA057 R 40-57
DP40L2 A27CGE40BA010
40 208-230
L 6-10
240 1.5 - 10
DP40M2 A27CGE40BA016 M 10-16
DP40N2 A27CGE40BA024 N 16-24
DP40P2 A27CGE40BA040 P 24-40
DP40L4 A27CGE40CA010
40 460
L 6-10
200 5 - 20
DP40M4 A27CGE40CA016 M 10-16
DP40N4 A27CGE40CA024 N 16-24
DP40P4 A27CGE40CA040 P 24-40
DP40L5 A27CGE40DA010
40 575
L 6-10
160 5 - 20
DP40M5 A27CGE40DA016 M 10-16
DP40N5 A27CGE40DA024 N 16-24
DP40P5 A27CGE40DA040 P 24-40
