Yamaha Jupiter MX - Installing the Kickstarter

ENG
4-74
90˚
1
2
a
b
4
3
KICKSTARTER
INSTALLING THE KICKSTARTER
1. Install:
9
kickstarter ratchet gear
1
(on to the kickstarter shaft)
9
kickstarter shaft
2
9
kickstarter spring
NOTE:
9
Offset the kickstarter ratchet gear as shown,
and then align the spline to install the kick-
starter ratchet gear.
9
Hook the kickstarter spring end onto the pin
a
in the crankcase, and then turn the kick-
starter shaft counter-clockwise to 3/4 turns
b
.
2. Install:
9
guide stopper
3
9
guide stopper bolts
9
kickstarter gear
4
3. Install:
9
crankcase
Refer to “CRANKCASE”.
4. Install:
9
engine
Refer to “REMOVING THE ENGINE”.
5. Install:
9
starter motor (T135SE)
Refer to “STARTER MOTOR (T135SE)” in
chapter 8.
6. Install:
9
oil pump assembly
Refer to “OILPUMP”.
9
generator
Refer to “GENERATOR AND STARTER
CLUTCH”.
9
shift shaft
Refer to “SHIFTSHAFT”.
9
clutch
Refer to “CLUTCH”.
7. Install:
9
gasket
9
dowel pins
9
crankcase cover bolts
9
crankcase cover (right)
9
oil level plug
8. Install:
9
kickstarter lever
9
kickstarter lever nut
12 Nm (1.2 m•kg, 9.0 ft•lb)
