Yamaha Jupiter MX - Assembling the Starter Motor; Installing the Starter Motor

ELEC
STARTER MOTOR (T135SE)
8-21
a
5. Measure:
9
brush length
a
Out of specification
→
Replace the brush-
es as a set.
6. Measure:
9
brush spring force
Out of specification
→
Replace the brush
springs as a set.
7. Check:
9
gear teeth
Damage/wear
→
Replace the armature.
EAS00772
ASSEMBLING THE STARTER MOTOR
1. Install:
9
O-ring
9
armature
(in start motor front cover
1
)
9
O-ring
9
starter motor yoke
9
starter motor front cover bolts
(with washers)
9
O-ring
NOTE:
Align the mark
a
on the starter motor yoke with
the mark
b
on the starter motor front cover.
INSTALLING THE STARTER MOTOR
For installation, reverse the removal procedure.
Brush length wear limit
3.5 mm (0.14 in)
Brush spring force
3.92–5.88 N (400–600 gf)
