Item Standard Limit
Steering system
Steering bearing type Ball and race bearing ----
Lock-to-lock angle (left/right) 45° ----
Front suspension
Front fork travel 100 mm (3.94 in) ----
Fork spring free length 295.3 mm (11.63 in) 289.4 mm
(11.39 in)
Installed length 288.3 mm (11.35 in) ----
Spring rate (K1) 3.60 N/mm (0.37 kgf/mm, 20.56 lb/in) ----
(K2) 8.50 N/mm (0.87 kgf/mm, 48.54 lb/in) ----
Stroke (K1) 0 – 65.0 mm (0.00 – 2.56 in) ----
(K2) 65 – 100 mm (2.56 – 3.94 in) ----
Optional spring available No ----
Oil capacity 0.064 L(64 cm
3
) ----
Oil level 104.5 mm (4.11 in) ----
Recommended oil Fork oil 10W or equivalent ----
Inner tube outer diameter 26 mm (1.02 in) ----
Inner tube bend limit ---- 0.2 mm
(0.0079 in)
Rear suspension
Shock absorber stroke 27.5 mm (1.0827 in) ----
Spring free length 115.4 mm (4.54 in) 113.1 mm
(4.4528 in)
Installed length 106.4 mm (4.19 in) ----
Spring rate (K1) 220 N/mm (22.43 kgf/mm, 1256.2 lb/in) ----
(K2) 316 N/mm (32.22 kgf/mm, 1804.36 lb/in) ----
Stroke (K1) 0.0 – 8.0 mm (0.00 – 0.31 in) ----
(K2) 8.0 – 27.5 mm (0.31 – 1.08 in) ----
Optional spring available No ----
Front wheel
Type Spoke wheel ----
Rim size 17
⋅
1.20 ----
Rim material Steel ----
Max. radial wheel runout ---- 1.0 mm
(0.04 in)
Max. lateral wheel runout ---- 0.5 mm
(0.02 in)
SPEC
2-11
MAINTENANCE SPECIFICATIONS
CHASSIS
