CHAS
FRONT BRAKE
7-19
a
5. Lubricate:
9
brake pad retaining pin
cC
9
Do not allow grease to contact the brake
pads.
9
Remove any excess grease.
6. Install:
9
brake caliper bolts
7. Check:
9
brake fluid level
Below the minimum level mark
a
→
Add
the recommended brake fluid to the proper
level.
Refer to “CHECKING THE BRAKE FLUID
LEVEL” in chapter 3.
8. Check:
9
brake lever operation
Soft or spongy feeling
→
Bleed the brake
system.
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM” in chapter 3.
EAS00619
DISASSEMBLING THE FRONT BRAKE
CALIPER
NOTE:
Before disassembling the brake caliper, drain
the brake fluid from the entire brake system.
Recommended lubricant
Lithium-soap-based grease
35 Nm (3.5 m·kg, 25 ft·lb)
To Next Page
