Yamaha Jupiter MX - Installing the Carburetor

CARB
CARBURETOR
6-10
2
1
2
3
1
5
4
a
b
3
2
1
EAS00492
INSTALLING THE CARBURETOR
1. Install:
9
needle set
2. Install:
9
joint
1
9
intake manifold
2
3. Connect:
9
fuel hose
1
9
carburetor overflow hose
2
9
vacuum sensing hose
3
9
air vent hose
4
9
vacuum sensing hose
5
4. Install:
9
carburetor assembly
9
intake manifold bolts
9
clamp screw
5. Install:
9
throttle valve assembly
NOTE:
9
Align the slit
a
of the throttle valve with the
tab
b
of the carburetor body.
9
Be careful to fall off the O-ring on the carbure-
tor top cover when installing the throttle valve
assembly.
6. Install:
9
accelerator pump cable
1
9
choke cable
2
9
o-ring
9
carburetor top cover
3
10 Nm (1.0 m·kg, 7.2 ft·lb)
10 Nm (1.0 m·kg, 7.2 ft·lb)
