CHAS
FRONT FORK
7-32
2
1
1
5. Remove:
9
front fork cap bolt
1
(with a 10-mm hexagonal wrench)
6. Loosen:
9
lower bracket pinch bolt
2
w
Before loosening the lower bracket pinch
bolt, support the front fork leg.
7. Remove:
9
front fork leg
EAS00655
DISASSEMBLING THE FRONT FORK
LEGS
The following procedure applies to both of the
front fork legs.
1. Remove:
9
fork spring
2. Drain:
9
fork oil
NOTE:
Stroke the inner tube
1
several times while
draining the fork oil.
3. Remove:
9
dust seal
1
9
oil seal clip
2
(with a flat-head screwdriver)
cC
Do not scratch the inner tube.
To Next Page
