CHAS
FRONT FORK
7-33
4. Remove:
9
damper rod assembly bolt
9
copper washer
NOTE:
While holding the damper rod assembly with a
10 mm hexagon nut/socket wrench
1
and the T-
handle
2
, loosen the damper rod assembly bolt
3
.
5. Remove:
9
inner tube
9
rebound spring
9
damper rod
NOTE:
Pull out the inner tube and damper rod together.
6. Remove:
9
oil seal
1
2
Rag
T-handle
90890-01326
