SPEC
2-10
MAINTENANCE SPECIFICATIONS
Drive sprocket Bolt M6 1 10 1.0 7.2
Main axle bearing retainer Screw M6 2 7 0.7 5.0
Clutch release adjusting locknut Nut M6 1 8 0.8 6.0
Shift pedal Bolt M8 1 18 1.8 13
Shift drum segment Bolt M6 1 12 1.2 9.0
Shift drum stopper lever Bolt M6 1 10 1.0 7.2
Shift lever stopper screw Screw M8 1 10 1.0 7.2
Pickup coil Bolt M6 2 10 1.0 7.2
Stator coil Bolt M6 3 10 1.0 7.2
Neutral switch Screw M5 2 4 0.4 2.9
Starter motor Bolt M6 2 10 1.0 7.2
Part to be tightened Part name
Thread
size
Q’ty
Tightening
torque
Remarks
Nmm·kgft·lb
LT
LT
LT
LT
LT
LT
LT
