SPEC
2-16
MAINTENANCE SPECIFICATIONS
Item Standard Limit
Electric starting system (T135SE)
Type Constant mesh ----
Starter motor
Model/manufacturer 5YP/PTMORIC ----
Operation voltage 12 V ----
Power output 0.20 kW ----
Armature coil resistance 0.032 – 0.039
Ω
at 20 ° C (68 ° F) ----
Brush overall length 7.0 mm (0.28 in) 3.5 mm
(0.14 in)
Spring force 3.92 – 5.88 N 3.92 N
(400-600 gf, 14.11 – 21.17 oz) (400 gf)
Commutator diameter 17.6 mm (0.69 in) 16.6 mm
(0.65 in)
Mica undercut (depth) 1.35 mm (0.05 in) ----
Starter relay (T135SE)
Model/manufacturer G4R/THA-OMRON ----
Amperage rating 50 A ----
Coil resistance 54 – 66
Ω
at 20 ° C (68 ° F) ----
Horn
Type Plane ----
Quantity 1 ----
Model/manufacturer GF-12/THA-NIKKO ----
Max. amperage 1.5 A ----
Performance 95 – 105 db (2 m) ----
Coil resistance 4.30 – 4.80
Ω
at 20 ° C (68 ° F) ----
Turn signal relay
Relay type Condenser ----
Model/manufacturer FZ222SD/THA-DENSO ----
Self-canceling device built-in No ----
Flasher frequency 75 – 95 cycle/min ----
Wattage 10 W
⋅
2 + 3.4 W ----
Fuel gauge
Model/manufacturer 5YP/THA-NIPPON SEIKI ----
Sender unit resistance- full 4 – 10
Ω
at 20 ° C (68 ° F) ----
- empty 90 – 100
Ω
at 20 ° C (68 ° F) ----
Circuit breaker
Circuit breaker type Fuse ----
Main 10 A ----
Reserve 10 A ----
