SPEC
CABLE ROUTING
2-30
å
∫
ç
∂
´
ƒ
1
2
3
4
5
1
Speedometer cable
2
Acceleration pump cable
3
Throttle cable
4
Fuel sender lead
5
Choke cable
å
Route the acceleration pump
cable into the right side of the
stay.
∫
Route the throttle cable into
the left side of the stay.
ç
Black plating joint.
∂
Pass through the fuel sender
lead in to the side hole of the
fuel tank.
´
Clamp the fuel sender lead
onto the hook of the box.
ƒ
White plating joint.
