OTHER OPERATIONS

10-2 DIO Monitor Display

Data indicating whether the I/O signals are on or off can be displayed on the screen. The operation

procedure is explained below.

10-2-1

Display from the monitor menu

1) On the initial screen, press

(MON).

[MENU]

select menu

1EDIT2OPRT3SYS 4MON

[MENU]

select menu

1EDIT2OPRT3SYS 4MON

[MON]

[MON-DIO]

select menu

1DIO 2DUTY

DI 00000000 00000000

DO 10100000 O:0 S:1

2) Next, press

(DIO).

3) The ON/OFF status of I/O signals is displayed.

For information about what the display shows,

refer to "4-3-4 DIO monitor screen".

4) To return to the initial screen, press

ESC

twice.
