7-2
7
EDITING POINT DATA
7-1 Manual Data Input
7-1 Manual Data Input
1) On the initial screen, press
F1
(EDIT).
[EDIT]
select menu
1PGM 2PNT 3UTL
[EDIT-PNT]
select menu
1MDI 2TCH 3DTCH4DEL
[MENU]
select menu
1EDIT2OPRT3SYS 4MON
[EDIT-PNT-MDI]
P0 = 0.00 [mm]
input data[_ ]
input data[_ ]
1CHG
[EDIT-PNT-MDI]
P500 = -19.27 [mm]
input data[21. 76_ ]
1CHG
[EDIT-PNT-MDI]
Pn : n = _
(point No) 0999
[EDIT-PNT-MDI]
P500 = 21.76 [mm]
1CHG
2) Next, press
F2
(PNT).
3) Press
F1
(MDI).
4) The currently selected point data in the execu-
tion program appears on the screen.
If you want to edit another point data, press the
STEP
UP
and
STEP
DOWN
keys to scroll the point data.
To directly select the point data, press
F1
(CHG).
5) Enter the point number you want to edit with
the number keys, and press .
6) Enter the point data with the number keys and
press .
7) The input data is then registered as point data.
