EDITING POINT DATA
7-5 Manual Release of Holding Brake
7-5 Manual Release of Holding Brake
The holding brake on the vertical type robot can be released. Since the movable part will drop when
the brake is released, attaching a stopper to protect the tool tip from being damaged is recommended.
1) Use the same procedure up to step 4 in "7-3
Direct Teaching".
2) Press
F3
(BRK).
[EDIT-PNT-DTCH]
take off the brake ?
1yes 2no
[EDIT-PNT-DTCH]
P0 = 0.00 [mm]
[ 0.00]
[EDIT-PNT-DTCH]
P0 = 0.00 [mm]
[ 0.00]
1CHG 2DO 3BRK
1CHG 2DO 3BRK
3) A confirmation message appears asking
whether to release the brake.
To release the brake, press
F1
(yes).
To cancel releasing the brake, press
(no).
4) The screen returns to step 2.
The brake stays released until
F3
(BRK) is
pressed again or the robot servo is turned on.
n
NOTE
Manual release of the holding brake is only possible on those robots equipped with a brake.
