15-4
15
SPECIFICATIONS
15-2 TPB
15-2 TPB
15-2-1
Basic specifications
TPB
Basic
specifications
External dimensions
Weight
Power consumption
Power supply
Cable length
Serial interface
Display
Keyboard
Emergency stop button
Auxiliary memory device
Ambient temperature
Storage temperature
Ambient humidity
Noise immunity
Applicable TPB
W107 × H235 × D47mm
590g
5 V, 200 mA max.
DC12V (supplied form the controller)
Standard 3.5m
RS-232C, one channel, for communications with controller
Liquid crystal, 20 characters × 4 lines
29 keys, membrane switch + emergency stop button
Normally-closed contact (with lock function)
IC memory card
0: to 40:
-10: to 65:
35 to 85% RH (no condensation)
Conforms to IEC61000-4-4 Level 2
Ver. 12.50 or later compatible with SRCP series
I/O
Others
General
specification
Model
Specification item
