Main display area
User Guide
-
32
-
AUX1–AUX8 channels
1 Displays the SEND FROM screen. (page 66)
2 Displays the EQ screen. (page 36)
3 Displays the GEQ screen. (page 63)
4 Displays the COMP screen. (page 41)
5 Displays the OUTPUT screen. (page 65)
6 Displays the CH VIEW screen. (page 51)
AUX 9/10–19/20 channels, SUB channel
1 Displays the SEND FROM screen. (page 66)
2 Displays the EQ screen. (page 36)
3 Displays the GEQ screen. (page 63)
4 Displays the COMP screen. (page 41)
5 Displays the OUTPUT screen. (page 65)
6 Displays the CH VIEW screen. (page 51)
