M BAND COMP (V1.1 and later)
Two-input, two-output three-band compressor. Each band has solo and gain reduction metering.
Parameter Range Description
Low Gain -12.0dB - +12.0dB Low-band gain.
Mid Gain -12.0dB - +12.0dB Mid-band gain.
High Gain -12.0dB - +12.0dB High-band gain.
Total Gain -72dB - +12dB Overall gain.
L-M XOver 21.2Hz - 8.00kHz Low-to-mid crossover frequency.
M-H XOver 21.2Hz - 8.00kHz Mid-to-high crossover frequency.
Knee 0 - 5 Crossover knee (all bands).
Make Up Off, On Automatically adjusts output level.
Low Thr -54dB - 0dB Low threshold.
Low Ratio 1:1 - ∞:1 Low ratio.
Low Attack 0ms - 120ms Low attack time.
Low Release 3.34ms - 42.7s Low release time.
Low Bypass Off, On Compression bypass feature for low.
Low Solo Off, On Solo feature for low.
Mid Thr -54dB - 0dB Mid threshold.
Mid Ratio 1:1 - ∞:1 Mid ratio.
Mid Attack 0ms - 120ms Mid attack time.
Mid Release 3.34ms - 42.7s Mid release time.
Mid Bypass Off, On Compression bypass feature for mid.
Mid Solo Off, On Solo feature for mid.
High Thr -54dB - 0dB High threshold.
High Ratio 1:1 - ∞:1 High Ratio
High Attack 0ms - 120ms High attack time.
High Release 3.34ms - 42.7s High release time.
High Bypass Off, On Compression bypass feature for high.
High Solo Off, On Solo feature for high.
