Yamaha TMAX TECH MAX User Manual

Instrument and control functions
5-16
5
5. When you finished changing the
settings, use the select switch to
highlight “ ”, and then push the
“MENU” switch to return to the
previous display.
6. Use the select switch to
highlight “ ”, and then push the
“MENU” switch to return to the
menu screen.
Meter panel brightness
1. Use the select switch to highlight
“Brightness”.
2. Push the “MENU” switch.
3. Use the select switch to select the
desired brightness level.
4. Push the “MENU” switch to return
to the menu screen.
Setting the clock
TIP
The clock uses a 12-hour time system.
1. Use the select switch to highlight
“Clock”.
2. Push the “MENU” switch.
3. When the hour digits are highlight-
ed, use the select switch to set the
hours.
4. Push the “MENU” switch, and the
minute digits are highlighted.
5. Use the select switch to set the
minutes.
UB3TE0E0.book Page 16 Tuesday, September 17, 2019 9:35 AM

Yamaha TMAX TECH MAX Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Transmission	V-Belt Automatic
Front Suspension	Telescopic forks
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	220 kg
Fuel Tank Capacity	15 litres
Lubrication System	Wet sump
Ignition System	TCI
Starter System	Electric
Front Suspension Travel	120 mm
Rear Suspension Travel	117 mm
Minimum Ground Clearance	135 mm
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Tyre	120/70R15
Rear Tyre	160/60R15
Overall Height	1, 420 mm - 1, 555 mm (adjustable windscreen)
