Yamaha TMAX TECH MAX User Manual

Periodic maintenance and adjustment
8-7
8
21 * Front fork
• Check operation and for oil leak-
age.
• Replace if necessary.
√√√√
22 *
Shock absorber as-
sembly
• Check operation and for oil leak-
age.
• Replace if necessary.
√√√√
23 *
Rear suspension re-
lay arm and con-
necting arm
pivoting points
• Check operation. √√√√
24 Engine oil
• Change (warm engine before
draining).
• Check oil level and vehicle for oil
leakage.
At the initial interval and when the oil change indicator flashes or
comes on.
√
25
Engine oil filter car-
tridge
•Replace. √√√
26 * Cooling system
• Check coolant level and vehicle
for coolant leakage.
√√√√√
• Change. Every 3 years
27 * V-belt • Replace. When the V-belt replacement indicator flashes [every 20000 km (12000 mi)]
28 *
Front and rear
brake switches
• Check operation. √√√√√√
29 *
Moving parts and
cables
• Lubricate. √√√√√
NO. ITEM CHECK OR MAINTENANCE JOB
ODOMETER READING
ANNUAL
CHECK
1000 km
(600 mi)
10000 km
(6000 mi)
20000 km
(12000 mi)
30000 km
(18000 mi)
4000
0 km
(24000 mi)
UB3TE0E0.book Page 7 Tuesday, September 17, 2019 9:35 AM

Yamaha TMAX TECH MAX Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Transmission	V-Belt Automatic
Front Suspension	Telescopic forks
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	220 kg
Fuel Tank Capacity	15 litres
Lubrication System	Wet sump
Ignition System	TCI
Starter System	Electric
Front Suspension Travel	120 mm
Rear Suspension Travel	117 mm
Minimum Ground Clearance	135 mm
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Tyre	120/70R15
Rear Tyre	160/60R15
Overall Height	1, 420 mm - 1, 555 mm (adjustable windscreen)
