ELECTRICAL SPECIFICATIONS
2-12
EAS20310
ELECTRICAL SPECIFICATIONS
Ignition system
Ignition system Transistorized coil ignition (digital)
Advancer type Digital
Ignition timing (B.T.D.C.) 5.0 °/1070 r/min
Engine control unit
Model/manufacturer TBDF55/DENSO
Transistorized coil ignition
Crankshaft position sensor resistance 248–372 Ω
Ignition coil
Model/manufacturer 83R/MORIC
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 1.92–2.88 Ω
Secondary coil resistance 9.52–14.28 kΩ
Spark plug cap
Material Resin
Resistance 10.0 kΩ
AC generator
Model/manufacturer B3GB/DENSO
Standard output 13.5 V, 28.0 A@5000 r/min
Field coil resistance 2.75–3.04 Ω
Armature coil resistance 0.19–0.21 Ω
Brush overall length 13.7 mm (0.54 in)
Limit 4.7 mm (0.19 in)
Brush spring pressure 5.10–5.69 N (18.36–20.48 oz) (520–580 gf)
Rectifier/regulator
Regulator type Semi conductor-field control
Model/manufacturer B3GB/DENSO
No load regulated voltage 14.2–14.8 V
Battery
Model YTZ14S
Voltage, capacity 12 V, 11.2 Ah
Specific gravity 1.310
Manufacturer GYM
Ten hour rate amperage 1.12 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 60 W/55.0 W × 1
Auxiliary light 12 V, 4.0 W × 1
Tail/brake light LED
Front turn signal light 12 V, 21.0 W × 2
Rear turn signal light 12 V, 21.0 W × 2
License plate light 12 V, 5.0 W × 1
Indicator light
Neutral indicator light 12 V, 1.7 W × 1

Yamaha XJR1300 2007 Specifications

General

Displacement	1251 cc
Bore x Stroke	79.0 mm x 63.8 mm
Compression Ratio	9.7:1
Fuel System	Fuel Injection
Ignition	TCI
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Front Brakes	Dual disc
Rear Brakes	Single disc
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Width	765 mm
Height	1, 115 mm
Seat Height	795 mm
Ground Clearance	135 mm
Fuel Capacity	21 liters
Engine Type	Air-cooled, 4-stroke, DOHC, 4-valve
Max Power	72 kW (98 PS) @ 8, 000 rpm
Max Torque	108.4 Nm @ 6, 000 rpm
Rear Suspension	Swingarm
